Aqualine Reverse Osmosis is a membrane process that can separate undesirable minerals from water where classical purification methods are insufficient. It can be used on sea water, well water with high conductivity and can produce water of high purity.
| MODEL |
FEEDING CAPACITY @20C m3/gün |
PERMEATE CAPACITY @20C m3 /gün |
MEMBRANE DIMENSIONS |
MEMBRANE QTY |
| MLT-140 |
10 |
5 |
4" X 40" |
1 |
| MLT-240 |
20 |
10 |
4" X 40" |
2 |
| MLT-340 |
25 |
15 |
4" X 40" |
3 |
| MLT-440 |
33,5 |
20 |
4" X 40" |
4 |
| MLT-640 |
50 |
30 |
4" X 40" |
6 |
| MLT-940 |
64,5 |
45 |
4" X 40" |
9 |
| MLT-1240 |
86 |
60 |
4" X 40" |
12 |
| MLT-1540 |
107,5 |
75 |
4" X 40" |
15 |
STANDART FEATURES
1 m3/day to 30 m3/day
- Membrane vessels FRP or Stainless Steel
- TFC Spiral wound membranes 2,5î or 4î diameter
- SS304 stainless steel vertical centrifuge high pressure pump ( available in between MLT 340 - MLT1540 )
- Brass body rotary type high pressure pump ( available in between MLT 125/1 - MLT 240 )
- Equipments between MLT 125-1 and MLT 640 has SS304 stainless steel frame
- Equipments between MLT 840 and MLT 1540 has ST-37 carbon steel or SS304 stainless steel frame
- 5 micron cartridge filter
- Low and high pressure pipings U-PVC / Zonder
- Solenoid automatic valves or equivalent valve
- Pressure adjustment valves in Pump outlet and waste water line
- Low and high pressure switches
- Product water and waste water flowmeters
- Reverse cycle flowmeters ( reverse cycle is available in between MLT 340 - MLT 1540 )
- Gliserin Filled Manometers
- Product Water Conductivity Meter
- Autoflush System
- RO Electronic Control Card, Alarm and Position Indicators
- 220 V/50Hz/1ph ( between MLT 125/1 - MLT 240 )
- 380 V/50Hz/3ph ( between MLT 340 - MLT 1540 )
